Outer tent
(roof, walls, mud flaps,
partition, groundsheets
and shade fly)
Base fabric: Woven high-density polyethylene (HDPE)
black fibres
Coating: White low density polyethylene (LDPE) on both
sides, 190 gsm ± 20 g. Fire retardancy: EN13823+AI
Inner tent Polycotton, White, 125 gsm ±5%
Mosquito nets Polyester. Outer tent: 7-9 holes per inch²
Inner tent: 20-25 holes per inch²
Frame All aluminium main pipes: outer diameter 19 mm
±0.5 mm, thickness 1.2 mm ±1%
Connectors: outer diameter adapted to main pipe,
thickness 1.5 mm ±1%
